G4 SPECIFICATION

PERFORMANCE
Top speed 50km/hr (31mi/hr)
Range 30-35km (18-22mi)
Hill climb 30% grade
Max recommended payload 90kg (200lbs)

ELECTRICS
Number of motors 2
Motor Type 63mm brushless DC, high torque
Transmission 4:1 belt drive
Battery 600Wh or 900Wh Li-ion
Recharge Time 2 - 2.5hrs
Control Wireless 2.4GHz hand controller
Light 10W LED headlight (white) & tail / brake light (red)

CHASSIS
Suspension system Aluminium independent double-wishbone
Backbone Aircraft grade aluminium
Shock Absorber Spring shocks, 60mm travel, adjustable pre-load & rebound
Tyre Pneumatic, 254mm (10") diameter
Overall dimension 1270mm (50") x 495mm (19.5") x 280mm (11")
